Centrifuge 5804/5804 R and 5810/5810 R
3 Error lists / Troubleshooting
3-20 Error lists/Troubleshooting
6: Lid locking
uuu – mean value of sensor lid locking position
x1,x2 – lid report left and right
yy – O = locking mechanism in upper dead centre=closed
U = locking mechanism in lower dead centre=open
– = undefined position
zzz – actual sensor value (Hall sensor junction plate)
7: Last error report
ww – last error
xx – error report before last etc.
8: Version
xxx – voltage version set
yy – software version
zzzzz – checksum EPROM (for factory settings only)
9: Current error indication (selectable via cursor key only directly after error)
xx – error number
yy – no. for locating the cause (for factory settings only)
zz – FC error number, if the frequency converter switches off with error 6
0 =no error message
1 =undervoltage
2 =overvoltage
4 =overtemperature FC
5 =overtemperature motor
7 =overcurrent FC
8 =interference EEROM FC
10 =no release
FA =reset by internal software and hardware
FF =serial interface timeout
6:uuu x1x2 yzzz
7:ww xx yy zz
8:xxx yy zzzz
9:Er xx yy zz
