Error lists/Troubleshooting 3-23
Centrifuge 5804/5804 R and 5810/5810 R
3 Error lists / Troubleshooting
Description of the individual service programs
Setting of the serial interface
START Program 1 (optional)
xxxxx = RS232
BBUS Selection by means of the PLUS button
disable
Factory setting: disable
Start – next step
xx device address 20...29 (Hex)
Factory setting: 20 H
By actuating the PLUS button the address to be set is continuously counted upwards.
Acknowledgement of the selected device address with START.
END – end of program – actuate the START button.
Voltage version (set after replacing PCB Control)
START Program 2
Start SE 2 – Voltage version is displayed
Button PLUS – Selection of the voltage version 230 – 115 – 100
Button PROG Value is stored in the EEPROM
(display 'ok')
Button START/STOP – End of program
Check of the display and keypad
START Program 3
1. Check of the display
1.5-s sound on and all digits displaying the pattern 0000––––
2. Check of the keypad
Input request '>' the button designation is displayed as text.
End of program by means of the STOP button (as a last button).
1• xxxxx
2. nxx
SP x x x
MSTM/0408
