Centrifuge 5804/5804 R and 5810/5810 R
3 Error lists / Troubleshooting
3-24 Error lists/Troubleshooting
Lid function test
START Program 4
l, r – left and right limit switch (1 = pressed / 0 = open)
ss – position OT in upper dead centre
UT in lower dead centre
un undefined intermediate position
xxx – current sensor value
yyy – sensor idle value (mean value)
Keys:
OPEN – lid open/closed – normal function
PLUS – pulse by pulse forwards
MINUS – pulse by pulse backwards
SPEED – erase counter for continuous lid latch test.
STOP – end of program
Initializing
START Program 5
STOP button – no initializing, return to program selection
PROG button – initializing is carried out
The nominal values set and the operating conditions are stored in the EEPROM after each run of the
centrifuge. The limits for switching off (imbalance) and statistical data and fixed programs are also
stored in the EEPROM.
When calling up the program via the serial interface – code no. 64, additionally the interface is set to
20 H/disable.
yyy l r ssxxx
Ini t 2
The following is deleted: The following is not deleted:
Error table Imbalance cut-off values (SE 10)
Number of connections (IO) Number of load changes per rotor (Clyy)
Operating hours (h) Voltage version
Total number of centrifuge runs (CL) Interface setting
Programmed customer fixed programs
MSTM/0408
