Eppendorf 5804 - Upper Housing Assembly Procedures; PCB Control;EPROM Replacement

Centrifuge 5804/5804 R and 5810/5810 R
4 Disassembly / Assembly
4-2 Disassembly/Assembly
5804/5804 R and 5810/5810 R Upper part of housing
Pre-condition: Remove front cover.
– 5804/5804 R only!
Remove 6 Phillips screws from rear panel.
– 5804/5804 R only!
Remove rear panel.
– 5804/5804 R only!
Disconnect plug from fan.
– Remove 2 Phillips screws at the rear side of the upper part of housing.
– 5404R/5810 R only!
Remove 2 Phillips screws at the right front side (cover of cooling aggregate).
– Remove cover of cooling aggregate. Disconnect ground connector.
– Remove 5 Phillips screws at the front side of upper part of housing.
– Take out black clamps of holder for front cover. This eases removal of upper part of housing.
– Pull side panels of upper part of housing outwards slightly and pull upwards.
– Remove connector from mains switch (note colors).
Mount upper part of housing in reverse order.
– Start device.
5804/5804 R and 5810/5810 R Replacing PCB Control/EPROM
Pre-condition: Remove front cover.
– Remove 5 Phillips screws.
– Disconnect 5 plugs.
– Disconnect 2 flat connectors.
– Disconnect plug X2.
– Replace PCB Control/pull EPROM.
Mount PCB Control/EPROM in reverse order.
– Start device. / carry out imbalance adjustment.
MSTM/0408
