Spare parts list 7-13
Centrifuge 5804/5804 R and 5810/5810 R
7 Spare parts list
3 5-2 EPROM software program for 5810/5810 R x x 5810 810.108
3 5-2 EPROM software program for 5810/5810 R for SMD x x 5810 850.100
3 5-2 EPROM software program for 5804/5804 R x x 5804 810.104
3 5-2 EPROM software program for 5804/5804 R for SMD x x 5804 850.106
2 5-3 PCB Imbalance detection x x x x 5820 850.027
3 5-4 Frequency converter for 230/202-V version*
1
x x x x 5810 855.250
3 5-4 Frequency converter for 120-V version*
1
x x x x 5810 855.241
3 5-5 Cable FC signals 5810/5810 R x x 5810 617.006
3 5-5 Cable FC signals 5804/5804 R x x 5810 622.000
5-6 Retrofit kit EDP connection, rear panel, 5804 x 5814 850.031
5-6 Retrofit kit EDP connection,
rear panel lamella protection, 5804 R
x 5815 850.035
5-6 Retrofit kit EDP connection, rear panel, 5810 x 5820 850.264
5-6 Retrofit kit EDP connection,
rear panel lamella protection, 5810 R
x 5821 850.276
5-7 Cable EDP connection to the PCB control x x x x 5811 855.458
5-8 PCB Interface 58xx (with EDP connection cable) x x x x 5811 855.504
6 Temperature sensors
6-1 Temperature switch for fan of power unit, 120 V x 5804 623.002
6-2 Temperature sensor (bottom of chamber) x x 5821 850.136
6-3 Lower counter nut for sensor holder x x 0113 202.653
6-4 Holder for temperature sensor, incl. nut x x 0113 202.483
4 6-5 Temperature sensor (condenser) x x 5811 645.003
7 Lid
11 7-1
Upper part of lid 5810/5810 R /with monitor glass*
2
x x 5810 160.510
12 7-1
Upper part of lid 5804/5804 R with monitor glass*
2
x x 5804 160.517
*
2
Note: Retrofit upper and lower part of lid together.
1 7-2 Phillips screw for lid, 16 long x x x x 0110 001.134
Fig. Pos. Designation
5804
5804 R
5810
5810 R
Part no.
MSTM/0408
*
1
Use only with Eprom software 4.x on PCB control.
