4 Technical description
4.1 Device construction
Fig. 1: Front view
1 Heated lid
2 Locking button
3 Display and control panel
4 Personal card reader
Fig. 2: Side view
1 Heated lid
2 Thermoblock
(not visible in this picture)
3 Ventilation slit
4 Brightness regulator
5 PC connection socket
6 Printer connection socket
Fig. 3: Rear view
1 Ventilation slit
2 Main power switch
3 Fuses
4 Main power socket
5 Identification plate
1
2
3
4
1
2
3
654
4
3
2
1
5
