Product description
Mastercycler
®
nexus
English (EN)
14
2.1.4 Eco variants
•Mastercycler nexus eco
•Mastercycler nexus gradient eco
•Mastercycler nexus SX1e
•Mastercycler nexus GSX1e
•Mastercycler nexus X2e (with a thermoblock with 64+32 wells; not shown in the figure)
•Mastercycler nexus GX2e (with a thermoblock with 64+32 wells; not shown in the figure)
•Mastercycler nexus flat eco (with a flat thermoblock; not shown in the figure)
Abb. 2-4: Front and rear view
Fig. 2-4: Front and rear view
1 Lid handle
For opening, closing, locking and unlocking the
heated lid.
2 Heated lid
3 Heating plate
4 Thermoblock
5Mains connection socket with power switch
0 = switched off, I = switched on.
6Eco and Term switches
7CAN out port
8CAN in port
9Pen holder
Holds up to three pens.
10 Name plate
eco
1
2 3
4
5
67
8
9
10
