Assembling steps
1. Pass the cable for the DM-D500 through the DM-D stand.
When extending the length of the DM-D stand, attach the extension
support (DP-105) to the DM-D stand.
2. Insert the tab on the DM-D500 (or the extension support) into the
hole on the DM-D stand until you feel it click.
3. Connect the cable for the DM-D500 to the display connector on the
DM-D stand until you feel it click.
When using the
extension support
(DP-105)
