Epson Artisan 725 - Disassembly;Assembly; Procedural Differences between the Models

Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD Revision G
Artisan 837/730/PX830FWD/PX730WD/TX730WD Disassembly/assembly 288
Confidential
9.4 Disassembly/assembly
9.4.1 Procedural Differences between the Models
The disassembly/reassembly procedures for some parts of Artisan 810/710/PX810FW/TX810FW/PX710W/TX710W, Artisan 835/725/PX820FWD/TX820FWD/PX720WD/
TX720WD and Artisan 837/730/PX830FWD/PX730WD/TX730WD are different. For the parts other than those mentioned in the following table, you can take the same procedures
for disassembling/assembling as those for the following models.
 Artisan 837/PX830FWD: same as those for Artisan 835/PX820FWD/TX820FWD
 Artisan 730/PX730WD/TX730WD: same as those for Artisan 725/PX720WD/TX720WD
When disassembling or assembling, check the following table, " 4.1.1 Precautions" (p.101), " 4.1.2 Tools" (p.102), and " 4.1.3 Work Completion Check" (p.102), and confirm " 9.4.2
Disassembly Procedures" (p.290) to see the appropriate disassembling/assembling procedures.
Table 9-6. Procedure Differences
Parts name
Differences
Reference page
Artisan 837/PX830FWD Artisan 730/PX730WD/TX730WD
 Upper Housing
 Rear Left Housing
 Left Housing
 Rear Right FAX
Housing (Artisan 837/
PX830FWD)/Rear Right
Housing (Artisan 730/
PX730WD/TX730WD)
 Right Housing
/Housing Front Right
 Scanner Upper Housing
 The shape of the housing is different from that for Artisan 835/725/PX820FWD/TX820FWD/
PX720WD/TX720WD.
 The number of screws and positions differs from that for Artisan 835/725/PX820FWD/
TX820FWD/PX720WD/TX720WD.
 Artisan 837/PX830FWD
 9.4.2.2 " Upper Housing " (p.294)
 9.4.2.4 " Rear Left Housing " (p.297)
 9.4.2.6 " Rear Right FAX Housing " (p.299)
 9.4.2.7 " Right Housing/Housing Front Right " (p.300)
 9.4.2.14 " Scanner Upper Housing " (p.307)
 Artisan 730/PX730WD/TX730WD
 9.4.2.17 " Upper Housing " (p.309)
 9.4.2.19 " Rear Left Housing " (p.313)
 9.4.2.20 " Rear Right Housing " (p.314)
 9.4.2.21 " Right Housing / Housing Front Right "
(p.315)
 9.4.2.23 " Scanner Upper Housing " (p.317)
 Decoration Plate Left
Upper Sub
 Decoration Plate Left
Upper
 Front Cover
 Housing Front Left
 Relay Board
 Document Cover Open
Sensor
 Newly added for Artisan 837/730/PX830FWD/PX730WD/TX730WD.
 The number of screws and positions differs between Artisan 837/PX830FWD and Artisan 730/
PX730WD/TX730WD because the shape of the parts is different.
 Artisan 837/730/PX830FWD/PX730WD/TX730WD
 9.4.2.8 " Front Cover " (p.301)
 9.4.2.9 " Housing Front Left " (p.301)
 9.4.2.11 " Relay Board " (p.304)
 9.4.2.12 " Document Cover Open Sensor " (p.304)
 Artisan 837/PX830FWD
 9.4.2.1 " Decoration Plate Left Upper Sub " (p.293)
 9.4.2.3 " Decoration Plate Left Upper " (p.296)
 Artisan 730/PX730WD/TX730WD
 9.4.2.16 " Decoration Plate Left Upper/Decoration
Plate Left Upper Sub " (p.308)
