Flowchart 9-1. Disassembling Flowchart (1)
Some pictures in this manual are for Epson Artisan 800/Epson Stylus Photo PX800FW/TX800FW and Epson Artisan 700/Epson
Stylus Photo PX700W/TX700W; therefore, the shapes of the parts are different from those of Artisan 837/730/PX830FWD/
PX730WD/TX730WD, but the differences do not affect the disassembly/reassembly procedures.
The colored blocks indicate the following.
• Red: Basically the disassembling procedures are in common with both Artisan 837/PX830FWD and Artisan 730/PX730WD/
TX730WD, but some parts differ in shape.
• Blue: Artisan 837/PX830FWD
only.
• Yellow: Artisan 730/PX730WD/TX730WD
only.
The parts surrounded with dotted line are not the shortest ways of removing them, but you need to remove the parts/units if they
exist on the way to the target part/unit.
When replacing the printer mechanism, see "4.2.1 Parts transferred from the old printer when replacing the Printer Mechanism"
(p.108) to transfer the parts from the old printer to the new one. Because some of the parts configuration of the exterior parts on
the right and the left (Group C, E) differ, make sure of the necessary parts to replace, and replace the Printer Mechanism.
When replacing the Head Supply Assy, see "4.2.2 Replacing the Head Supply Assy" (p.109).
Start
"4.2.3.12 Cassette Unit/EJ
Cover Assy " (p.122)*
"4.3.1.1 Scanner Unit "
(p.179)
"9.4.2.1 Decoration Plate
Left Upper Sub " (p.293)
"4.2.3.13 Paper Guide
Top Assy " (p.123)
"9.4.2.17 Upper Housing "
(p.309)
(
Artisan 730/
PX730WD/TX730WD
)
"4.2.3.13 Paper Guide
Top Assy " (p.123)
"4.2.3.9 Rear ASF Paper
Guide Cover " (p.119)
"4.2.5.11 Waste Ink Tray
Assy " (p.156)
"8.3.2.1 ADF Unit " (p.264)
(Artisan 835/PX820FWD/
TX820FWD)
"4.2.5.12 Lower Paper
Guide Waste Ink Pad
Assy " (p.159)
"4.2.5.10 Pick-up Roller "
(p.155)
"9.4.2.1 Decoration Plate
Left Upper Sub " (p.293)
See Flowchart 9-3 Disassembling Flowchart (3) (p292)
for disassembling procedures of the Scanner Unit and
the ADF Unit.
"4.2.3.3 Hinge " (p.113)
?9.4.2.16 Decoration Plate
Left Upper/Decoration Plate
Left Upper Sub ?
(p308)
"9.4.2.8 Front Cover "
(p.301)
"9.4.2.22 Scanner Open
Sensor " (p.316)
(
Artisan
730/PX730WD/TX730WD
)
"9.4.2.11 Relay Board "
(p.304)
A
(p291)
"9.4.2.18 Panel Unit "
(p.311)
(
Artisan 730/
PX730WD/TX730WD
)
Note " * " : Artisan 837/730/PX830FWD/PX730WD/TX730WD do
not have the EJ Cover, therefore, the disassembly/
reassembly related to the EJ Cover is not necessary.
"4.2.5.13 Front Paper
Guide Waste Ink Pad "
(p.159)
To Next Page
