Epson BrightLink 697Ui Installation Guide

22
Measurements in Centimeters for WXGA Projectors in Native Resolution
* Based on an image 76.2 cm from the floor; if the image is lower, the minimum ceiling height is reduced by the corresponding
measurement.
Diagonal
image size (S)
Min. ceiling
height*
width (w)
height (h)
Min. projection
distance (a)
Sliderscale
mark (b)
Distance from top
of image to
bottom wall plate
holes (c)
Distance from top
of image to
temporary wall
plate hole (d)
60"
199.9 129.2 80.8 3.8 14.5 17.5 36.7
61"
201.5 131.4 82.1 4.4 15.1 17.8 37.0
62"
203.1 133.5 83.4 5.0 15.7 18.1 37.3
63"
204.8 135.7 84.8 5.6 16.3 18.4 37.6
64"
206.4 137.9 86.2 6.3 17.0 18.6 37.8
65"
208.0 140.0 87.5 6.9 17.6 18.9 38.1
66"
209.6 142.2 88.8 7.5 18.2 19.2 38.4
67"
211.3 144.3 90.2 8.1 18.8 19.5 38.7
68"
212.9 146.5 91.5 8.7 19.4 19.8 39.0
69"
214.5 148.6 92.9 9.3 20.0 20.0 39.2
70"
216.2 150.8 94.3 10.0 20.7 20.3 39.5
71"
217.8 152.9 95.6 10.6 21.3 20.6 39.8
72"
219.4 155.1 96.9 11.2 21.9 20.9 40.1
73"
221.0 157.2 98.2 11.8 22.5 21.2 40.4
74"
222.7 159.4 99.7 12.4 23.1 21.4 40.6
75"
224.3 161.5 101.0 13.1 15.1 21.7 40.9
76"
225.9 163.7 102.3 13.7 15.7 22.0 41.2
77"
227.5 165.9 103.6 14.3 16.3 22.3 41.5
78"
229.2 168.0 105.0 14.9 16.9 22.6 41.8
79"
230.8 170.2 106.4 15.5 17.5 22.8 42.0
80"
232.4 172.3 107.7 16.1 18.1 23.1 42.3
81"
234.0 174.5 109.0 16.8 18.8 23.4 42.6
82"
235.7 176.6 110.4 17.4 19.4 23.7 42.9
83"
237.3 178.8 111.7 18.0 20.0 24.0 43.2
84"
238.9 180.9 113.1 18.6 20.6 24.2 43.4
85"
240.6 183.1 114.5 19.2 21.2 24.5 43.7
86"
242.2 185.2 115.8 19.9 21.9 24.8 44.0
87"
243.8 187.4 117.1 20.5 22.5 25.1 44.3
88"
245.4 189.5 118.4 21.1 23.1 25.4 44.6
89"
247.1 191.7 119.9 21.7 23.7 25.6 44.8
90"
248.7 193.9 121.2 22.3 24.3 25.9 45.1
91"
250.3 196.0 122.5 22.9 24.9 26.2 45.4
92"
251.9 198.2 123.8 23.6 25.6 26.5 45.7
93"
253.6 200.3 125.2 24.2 26.2 26.8 46.0
94"
255.2 202.5 126.5 24.8 26.8 27.1 46.3
95"
256.8 204.6 127.9 25.4 27.4 27.3 46.5
96"
258.4 206.8 129.2 26.0 28.0 27.6 46.8
97"
260.1 208.9 130.6 26.7 28.7 27.9 47.1
98"
261.7 211.1 131.9 27.3 29.3 28.2 47.4
99"
263.3 213.2 133.2 27.9 29.9 28.5 47.7
100"
265.0 215.3 134.7 28.5 30.5 28.7 47.9
