A.1 CONNECTOR SUMMARY
The figure below shows the interconnection between the major components of the Epson Stylus Color
200/Epson Stylus 200.
AC INLET
C160PSB
CN1
CN2 CN6
CN1
CN7
PE
CN9
ASF
CN8
HP
C199MAIN
CN4
CN5
CN3
Centronics
PF MOTOR
CR MOTOR
CN2
SERIAL
Head
Figure A-1. Interconnection of Major Components
