Epson DS-870 - Page 108

4. Open the cover of the pickup roller, and then slide and remove it.
5. Pull down the xture of the roller axis, and then slide and remove the installed pickup rollers.
c
Important:
Do not pull out the pickup roller forcibly. is could damage the inside of the scanner.
User's Guide
Maintenance
108
