Epson EB-1880 User Manual

g
When the message "Save this image as the User's Logo?" is
displayed, select Yes.
The image is saved. After the image has been saved, the message
"Completed." is displayed.
a
• When a User's Logo is saved, the previous User's Logo is
erased.
• It takes a while to save. Do not operate the projector or any
connected equipment while it is saving, otherwise
malfunctions may occur.
Saving User Pattern
You can save the image that is currently being projected as a User Pattern.
a
When a User Pattern is saved, the previous User Pattern is erased.
a
Project the image you want to use as the User Pattern, and then
press the [Menu] button.
s
"Using the Configuration Menu" p.74
Using the remote control Using the control panel
b
Select Pattern from Settings.
c
Select User Pattern.
a
If User Pattern is selected when Keystone, E-Zoom, Aspect, or
Zoom adjustment are being performed, the function currently
being performed is temporarily cancelled.
Projection Functions
57

Epson EB-1880 Specifications

Display

native resolution	1024 x 768 (XGA)
color light output	4000 lumens
white light output	4000 lumens (ISO 21118 standard)

Power

power consumption (normal mode)	363 W
power consumption (eco mode)	297 W
power supply voltage	100 – 240 V ± 10%, 50/60 Hz AC

Projection Lens

f-number	1.51 – 1.99
focal length	18.2 mm – 29.2 mm
zoom ratio	1.0 – 1.6

Operating Environment

operating temperature	5˚ to 35˚C
fan noise (normal mode)	39 dB
fan noise (eco mode)	35 dB

Lamp

lamp type	275 W UHE E-TORL
lamp life (normal mode)	3000 hours
lamp life (eco mode)	4000 hours

Weight and Dimensions

weight	3.3 kg
dimensions (including feet)	345 x 263 x 103 mm
dimensions (excluding feet)	345 x 263 x 93 mm
