Interacting with the Screen
101
Control commands Connection method
ESC/P-R Over a network
ESC/Page, ESC/Page-Color
PCL6
* Not all printers are supported. For more details on supported models,
contact Epson for help.
a
Select the icon on the bottom toolbar.
The Print screen is displayed.
b
Specify the number of copies on the Print screen (up to 20 sheets).
c
Select Print.
Selecting Network Device Display
If you have connected devices to the projector via a network, you can select to
project an image from those devices. You can select the image source from
computers that are running EasyMP Multi PC Projection, and smartphones
or tablets that are running Epson iProjection.
a
You can select any connected network device for projection, even if the
user connected using the EasyMP Multi PC Projection software with
the moderator feature enabled. See the EasyMP Multi PC Projection
Operation Guide for details about the moderator feature.
a
Select the icon on the bottom toolbar, and then select Participant
List from the image source list.
The user selection screen is displayed.
b
Select the user name for the device you want to project from.
A
Displays the user names for network devices connected to the projector.
The icon is shown next to the user name of the currently projected
device (Only when displaying pages with icons).
B
Closes the user selection screen and returns to the previous screen.
C
Click to move to the previous page or the next page when displaying a
thumbnail.

Table of Contents

Other manuals for Epson EB-670

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-670 and is the answer not in the manual?

Epson EB-670 Specifications

General IconGeneral
Matrix size0.55 \
Number of colors1.073 billion colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Contrast ratio (dynamic)14000:1
Contrast ratio (typical)300:1
Screen size compatibility56 - 93 \
Projection distance (tele)0 - 32 m
Projection distance (wide)0 - 0.4 m
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal±3 °
Projector brightness (economic mode)1800 ANSI lumens
Noise level35 dB
Country of originPhilippines
2D/3D frequency image100 - 120 Hz
On Screen Display (OSD)Yes
Noise level (economic mode)28 dB
Mac operating systems supportedMac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
RMS rated power16 W
Number of built-in speakers1
FocusManual
Digital zoom1.35 x
Focal length range0 - 3.76 mm
PlacementWall
Product typeUltra short throw projector
Product colorGrey, White
Cable lock slot typeKensington
Built-in displayNo
Lamp power215 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Power sourceAC
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.39 W
Power consumption (typical)311 W
Power consumption (PowerSave)226 W
Color modes (2D)Cinema, Dynamic
Video processing10 bit
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system-
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232C
USB 2.0 ports quantity2
S-Video inputs quantity0
VGA (D-Sub) ports quantity3
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedUSB
Bundled softwareEasyMP Monitor, EasyMP Multi PC Projection
Remote control typeIR
Pallet width800 mm
Pallet height150 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet12 pc(s)
Quantity per pallet layer2 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width367 mm
Height149 mm
Weight5700 g
Package depth730 mm
Package width490 mm
Package height335 mm
Package weight18752 g
