Epson EB-670 User Manual

Projecting a PC Free Presentation
116
• Some commercially available USB card readers may not be compatible with
the projector.
• The projector can recognize up to 5 cards inserted into the connected card
reader at one time.
• You cannot correct keystone distortion while projecting in PC Free, so
correct the image shape before you begin your presentation.
• You can use the following functions while projecting in PC Free.
• Freeze
• A/V Mute
• E-Zoom
• Pointer
gg Related Links
• "Stopping Video Action Temporarily" p.121
• "Shutting Off the Image and Sound Temporarily" p.120
• "Zooming Images" p.122
• "Using the Remote Control as a Pointer" p.125
Starting a PC Free Slide Show
After connecting a USB device to the projector, you can switch to the USB
input source and start your slide show.
a
• You can change the PC Free operation options or add special effects
by highlighting Option at the bottom of the screen and pressing
[Enter].
• You can operate your slide show using the interactive pen or your
finger instead of the remote control (EB-695Wi/EB-685Wi/EB-
680Wi/EB-675Wi).
a
Press the [USB] button on the remote control.
The PC Free file list screen is displayed.
a
• If the Select Drive screen is displayed, press the arrow buttons
to select the drive and press [Enter].
• To display the Select Drive screen, highlight Select Drive at the
top of the file list screen and press [Enter].
b
Do one of the following to locate your files:
• If you need to display files inside a subfolder on your device, press
the arrow buttons to highlight the folder and press [Enter].
• To move back up a folder level on your device, highlight Back to
Top and press [Enter].
• To view additional files in a folder, highlight Next Page or Previous
Page and press [Enter], or press the [Page] up or down buttons on
the remote control.
c
Do one of the following:
• To display an individual image, press the arrow buttons to highlight
the image and press [Enter]. (Press the [Esc] button to return to the
file list screen.)

Epson EB-670 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Contrast ratio (dynamic)	14000:1
Contrast ratio (typical)	300:1
Screen size compatibility	56 - 93 \
Projection distance (tele)	0 - 32 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	±3 °
Projector brightness (economic mode)	1800 ANSI lumens
Noise level	35 dB
Country of origin	Philippines
2D/3D frequency image	100 - 120 Hz
On Screen Display (OSD)	Yes
Noise level (economic mode)	28 dB
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
RMS rated power	16 W
Number of built-in speakers	1
Focus	Manual
Digital zoom	1.35 x
Focal length range	0 - 3.76 mm
Placement	Wall
Product type	Ultra short throw projector
Product color	Grey, White
Cable lock slot type	Kensington
Built-in display	No
Lamp power	215 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.39 W
Power consumption (typical)	311 W
Power consumption (PowerSave)	226 W
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232C
USB 2.0 ports quantity	2
S-Video inputs quantity	0
VGA (D-Sub) ports quantity	3
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	USB
Bundled software	EasyMP Monitor, EasyMP Multi PC Projection
Remote control type	IR
Pallet width	800 mm
Pallet height	150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	400 mm
Width	367 mm
Height	149 mm
Weight	5700 g
Package depth	730 mm
Package width	490 mm
Package height	335 mm
Package weight	18752 g
