Projector Parts and Functions
15
Name Function
G
HDMI1/MHL port Inputs video signals from HDMI compatible video
equipment and computers, or MHL (Mobile High-
Definition) compatible mobile devices.
This projector is compatible with HDCP.
H
Monitor Out/
Computer2 port
When Monitor Out Port is set to Monitor Out in the
projector's Extended menu, analog RGB signals input
from the Computer1 port are output to an external
monitor. You cannot output signals input from other
ports or component video signals.
When Monitor Out Port is set to Computer2 in the
projector's Extended menu, image signals from a
computer and component video signals from other
video sources are input.
s Extended > Operation > Monitor Out Port
I
HDMI2 port Inputs video signals from HDMI compatible video
equipment and computers.
This projector is compatible with HDCP.
J
HDMI3 port Inputs video signals from HDMI compatible video
equipment and computers.
This projector is compatible with HDCP.
K
RS-232C port Connects an RS-232C cable to control the projector
from a computer. (This port is for control use and
should not normally be used.)
L
SYNC IN/OUT port
(EB-695Wi/EB-
685Wi/EB-
680Wi/EB-675Wi)
When using the interactive features in the same room
as multiple versions of the same projector, you need to
connect the optional remote control cable set to the
projectors. When the cable set is connected, the
interactive pen operates smoothly.
M
Power inlet Connects the power cord to the projector.
N
TCH port
(EB-695Wi/EB-
680Wi)
Connects the supplied Touch Unit connection cable to
the Touch Unit.
O
USB-A port Connects a USB memory device or a digital camera
and projects movies or images using PC Free.
Connects the optional Document Camera.
Name Function
P
Video port Inputs composite video signals from video sources.
Q
Audio port Inputs audio from equipment connected to the Video
port.
Inputs audio from other devices when projecting
images from the device connected to the USB-A port.
R
Audio Out port Outputs audio from the current input source or Mic
port to an external speaker.
S
Mic port Inputs audio from the microphone.
