Input Signal Settings - Signal Menu
131
Normally the projector automatically detects and optimizes the input signal
settings. If you need to customize the settings, you can use the Signal menu.
The available settings depend on the currently selected input source.
a
You can restore the default settings of the Tracking, Sync., and
Position settings by pressing the [Auto] button on the remote control.
To change settings for an input source, make sure the source is connected and
select that source.
Setting Options Description
Resolution Auto
Wide
Normal
Sets the input signal resolution if not
detected automatically using the Auto
option.
Aspect See the list of
available aspect
ratios.
Sets the aspect ratio (width-to-height
ratio) for the selected input source.
Tracking Varying levels
available
Adjusts the signal to eliminate vertical
stripes in computer images.
Sync. Varying levels
available
Adjusts the signal to eliminate fuzziness
or flickering in computer images.
Setting Options Description
Position — Adjusts the image location on the screen.
Auto Setup On
Off
Automatically optimizes computer image
quality (when On).
Overscan Auto
Off
4%
8%
Changes the projected image ratio to
make the edges visible by a selectable
percentage or automatically.
Advanced Video Range Video Range: sets the video range to
match the setting of the device connected
to the HDMI port.
Video Signal Video Signal: specifies the signal type
from the input sources connected to the
Video ports. If interference appears or no
image appears when set to Auto, select
the appropriate signal according to the
connected equipment.
Reset — Resets all adjustment values on the
Signal menu to their default settings.
gg Related Links
• "Available Image Aspect Ratios" p.58
