Epson EB-992F User Manual

Projector Connections
29
a
• If the projector does not project any images, do one of the following:
• Windows: Click All Programs > EPSON Projector > Epson USB
Display > Epson USB Display Ver.x.xx.
• Mac: Double-click the USB Display icon in the Application folder.
• When you finish projection, do one of the following:
• Windows: Disconnect the USB cable. You do not need to operate
Safely Remove Hardware.
• Mac: Select Disconnect from the USB Display icon menu on the
menu bar or Dock, and then disconnect the USB cable.
gg Related Links
• "USB Display System Requirements" p.203
• "List of Functions" p.10
Connecting to a Computer for HDMI Video and Audio
If your computer has an HDMI port, you can connect it to the projector using
an HDMI cable and send the computer's audio with the projected image.
a
To connect a Mac that does not have an HDMI port, you need an
adapter that allows you to connect to the projector's HDMI port.
Contact Apple for compatible adapter options. Older Mac computers
(2009 and earlier) may not support audio through the HDMI port.
a
Connect the HDMI cable to your computer's HDMI output port.
b
Connect the other end to the projector's HDMI port.
a
If you have problems hearing audio through the HDMI connection,
connect one end of a commercially available 3.5 mm stereo mini-jack
audio cable to the projector's Audio port and the other end to your
computer's audio out port. Select the audio input port you connected
to in the projector's Extended menu.
s Extended > A/V Settings > Audio Settings > HDMI Audio
Output
s Extended > A/V Settings > Audio Settings > HDMI1 Audio
Output
s Extended > A/V Settings > Audio Settings > HDMI2 Audio
Output
gg Related Links
• "Projector Setup Settings - Extended Menu" p.134
• "List of Functions" p.10
Connecting to Video Sources
Follow the instructions in these sections to connect video devices to the
projector.

Epson EB-992F Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	1.76 - 2.86 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2400 ANSI lumens
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	6500 h
Service life of light source (economic mode)	17000 h
3D	No
Full HD	Yes
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Throw ratio	1.32 - 2.14:1
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.51 - 1.99
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
RMS rated power	16 W
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projektor Management
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	1
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	72 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	282 mm
Width	309 mm
Height	90 mm
Weight	3100 g
Package depth	390 mm
Package width	385 mm
Package height	170 mm
Package weight	4592 g
