Projecting a PC Free Presentation
71
b
Do one of the following to locate your files:
If you need to display files inside a subfolder on your device, press
the arrow buttons to highlight the folder and press [Enter].
To move back up a folder level on your device, highlight Back to
Top and press [Enter].
c
To play back a movie, press the arrow buttons to highlight the file and
press [Enter].
a
If any file names are longer than the display area or include
unsupported symbols, the file names may be shortened or
changed only on the screen display.
If you want to play back all the movies in a folder in sequence,
select the Slideshow option at the bottom of the screen.
d
To stop movie playback, press the [Esc] button, highlight Exit, and
press [Enter].
You return to the file list screen.
e
Turn off the USB device, if necessary, and then disconnect the device
from the projector.
gg Related Links
"PC Free Display Options" p.71
"Connecting to a USB Device" p.31
PC Free Display Options
You can select these display options when using PC Free. To access this
screen, highlight Option at the bottom of the PC Free file list screen and press
[Enter].
Setting Options Description
Display Order Name Order Displays files in name order
Date Order Displays files in date order
Sort Order In Ascending Sorts files in first-to-last order
In Descending Sorts files in last-to-first order
Continuous Play On Displays a slide show continuously
Off Displays a slide show once
Screen Switching
Time
No Does not display the next file
automatically
1 Second to 60 Seconds Displays files for the selected time
and switches to the next file
automatically; high resolution images
may switch at a slightly slower rate

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-992F and is the answer not in the manual?

Epson EB-992F Specifications

General IconGeneral
Matrix size0.61 \
Number of colors1.07 billion colors
Native aspect ratio16:9
Projection distance1.76 - 2.86 m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Contrast ratio (typical)16000:1
Screen size compatibility30 - 300 \
Projector native resolution1080p (1920x1080)
Keystone correction, vertical-30 - 30 °
Projector brightness (economic mode)2400 ANSI lumens
Lamp typeUHE
Lamp power230 W
Light source typeLamp
Service life of light source6500 h
Service life of light source (economic mode)17000 h
3DNo
Full HDYes
Video processing10 bit
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system-
Throw ratio1.32 - 2.14:1
Focal length range18.2 - 29.2 mm
Aperture range (F-F)1.51 - 1.99
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
RMS rated power16 W
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Power consumption (typical)327 W
Power consumption (economy mode)225 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Multi PC Projection, Epson Projektor Management
HDMI connector typeFull-size
Serial interface typeRS-232C
USB 2.0 ports quantity1
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
USB display function3 in 1: Image / Mouse / Sound
Supported network protocolsPJLink
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet72 pc(s)
Harmonized System (HS) code85286200
Software supportvia: AMX, Crestron (Network), Control4, Extron
Weight and Dimensions IconWeight and Dimensions
Depth282 mm
Width309 mm
Height90 mm
Weight3100 g
Package depth390 mm
Package width385 mm
Package height170 mm
Package weight4592 g
