Epson EB-W52 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 12 Revision A
1.2 Specifications
 EB-E01/X06/W06/E10/X51/W51/W52
Model
EB-E01 EB-X06 EB-W06 EB-E10 EB-X51 EB-W51 EB-W52
Item
Specific
ation
of main
part
LCD
Size
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.59 inch
(C2fine)
Pixel number
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
1,024,000 pixels
(1280 x 800) x 3
Native resolution XGA XGA WXGA XGA XGA WXGA WXGA
Aspect ratio 4:3 4:3 16:10 4:3 4:3 16:10 16:10
Projection Lens
Focus Type Manual
Zoom
Type Digital Manual Manual Digital Manual Manual Manual
Ratio 1-1.35 1-1.2 1-1.2 1-1.35 1-1.2 1-1.2 1-1.2
Lamp
Type UHE
Power consumption 210W
Life
Normal 6,000 hours
Eco 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,300lm 3,600lm 3,700lm 3,600lm 3,800lm 4,000lm 4,000lm
Eco mode
Color mode: Dynamic,
Zoom: Wide
2,200lm 2,400lm 2,400lm 2,200lm 2,500lm 2,600lm 2,600lm
Sound output Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding)
RCA — 1 (Yellow) 1 (Yellow) — 1 (Yellow) 1 (Yellow) 1 (Yellow)
Digital HDMI 1
Video output Analog D-sub 15pin —
Audio
Input
RCA (L/R)—11—111
Stereo mini —
Output Stereo mini —
Mic Input Stereo mini —

Epson EB-W52 Specifications

General

Matrix size	0.59 \
Matrix type	3-panel (p-Si TFT active)
Native aspect ratio	16:10
Projection distance	1.68 - 2.02 m
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
RMS rated power	2 W
Focus	Manual
Throw ratio	1.3 - 1.56
Focal length range	16.9 - 20.28 mm
Product type	Standard throw projector
Product color	Black, White
Market positioning	Home cinema
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 / 60 Hz
Power consumption (typical)	327 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Noise level (economic mode)	28 dB

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	92 mm
Weight	2600 g
