Supported
Monitor
Display
Resolutions
89
Signal
Refresh
rate
(Hz)
Resolution
(dots)
VGA
60
640
×
480
SDTV
(480i/480p)
59.94
720
×
480
SDTV
(576i/576p)
50
720
×
576
HDTV
(720p)
50/59.94/60
1280
×
720
HDTV
(1080i)
50/59.94/60
1920
×
1080
HDTV
(1080p)
23.98/24/29.97/30/50/59.94/60
1920
×
1080
88
90
Table of Contents
Table of Contents
2
Notations Used in this Guide
5
Introduction to Your Projector
8
Projector Parts and Functions
9
Projector Parts - Front/Top
9
Projector Parts - Rear
10
Projector Parts - Base
10
Projector Parts - Control Panel
11
Projector Parts - Remote Control
12
Name Function
12
Setting up the Projector
14
G G Related Links
14
Projector Placement
15
Projector Setup and Installation Options
16
Focusing the Image Using the Focus Lever
16
Projection Distance
17
Projector Connections
18
Connecting to a Streaming Media Player
18
Connecting to Video Sources
20
Connecting Headphones
21
Connecting to Bluetooth Audio Devices
22
Bluetooth Specifications
23
Installing Batteries in the Remote Control
24
Remote Control Operation
24
Using Basic Projector Features
26
Turning on the Projector
27
Turning off the Projector
28
Selecting the Language for the Projector Menus
29
Projection Modes
30
Changing the Projection Mode Using the Menus
30
Adjusting the Image Height
31
Image Shape
32
Auto V-Keystone
32
Correcting the Image Shape Horizontally with the Horizontal Keystone Buttons
32
Correcting the Image Shape with the Keystone Button
33
Correcting the Image Shape with Quick Corner
34
Image Shape
34
Focusing the Image Using the Focus Lever
36
Resizing the Image with Zoom
37
Image Aspect Ratio
38
Changing the Image Aspect Ratio
38
Available Image Aspect Ratios
39
Projected Image Appearance with each Aspect Mode
39
Adjusting Image Quality (Color Mode)
40
Changing the Color Mode
40
Available Color Modes
40
Turning on Automatic Luminance Adjustment
40
Adjusting the Sharpness
42
Adjusting the Image Color
43
Adjusting the Color Temperature
43
Adjusting the RGB Offset and Gain
43
Adjusting the Hue, Saturation, and Brightness
44
Adjusting the Gamma
45
Adjusting the Light Source Brightness
47
Saving Settings to Memory and Using Saved Settings
48
Controlling the Volume with the Volume Buttons
49
Changing the Sound Mode
50
Available Sound Modes
50
Adjusting Projector Features
51
HDMI Link Features
52
Operating the Connected Devices Using the HDMI Link Features
52
Shutting off the Image and Sound Temporarily (A/V Mute)
54
Projector Security Features
55
Locking the Projector's Buttons
55
Unlocking the Projector's Buttons
55
Installing a Security Cable
56
Adjusting the Menu Settings
57
Using the Projector's Menus
58
Using the Displayed Keyboard
59
Available Text Using the Displayed Keyboard
59
Image Quality Settings - Image Menu
60
Projector Feature Settings - Settings Menu
61
Projector Information Display - Info Menu
64
Info Menu - Projector Info Menu
64
Projector Reset Options - Reset Menu
66
Maintaining the Projector
67
Projector Maintenance
68
Cleaning the Projection Window
69
Cleaning the Projector Case
70
Air Filter and Vent Maintenance
71
Cleaning the Air Filter and Vents
71
Replacing the Air Filter
71
Solving Problems
73
Projection Problems
74
Projector Indicator Status
75
Solving Projector Power-On or Power-Off Problems
77
Solving Projector Power Problems
77
Solving Projector Shutdown Problems
77
Solving Image Problems
78
Solving Missing Image Problems
78
Adjusting an Image that Is Not Rectangular
78
Adjusting a Fuzzy or Blurry Image
79
Fixing Partial Image Problems
79
Adjusting an Image that Contains Noise or Static
79
Adjusting an Image with Incorrect Brightness or Colors
80
Adjusting an Upside-Down Image
80
Solving Missing or Low Audio Problems
81
Solving Bluetooth Problems
82
Solving Remote Control Operation Problems
83
Solving HDMI Link Problems
84
Appendix
85
Optional Accessories and Replacement Parts
86
Mounts
86
Replacement Parts
86
Screen Size and Projection Distance
87
Supported Monitor Display Resolutions
89
Projector Specifications
90
Connector Specifications
90
External Dimensions
91
List of Safety Symbols and Instructions
92
Laser Safety Information
94
Laser Warning Labels
94
Glossary
96
Notices
97
FCC Compliance Statement
97
Indication of the Manufacturer and the Importer in Accordance with Requirements of EU Directive
98
Restriction of Use
98
Trademarks
98
Copyright Notice
99
Copyright Attribution
99
