Epson EB-X11 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Product Description CONFIDENTIAL
SEIKO EPSON 14 Revision C
Operating Altitude
Normal 0 m to 2286 m <0 ft to 7500 ft>
High altitude mode Over 1500 m / 4,921 ft
Start-up period 5 seconds
Warm-up period 30 seconds
Cool-down period Instant off
Power supply voltage 100 - 240 V AC
± 10%, 50/60 Hz
Power
Consumption
100-120V
Area
(JAPAN,
USA,etc.)
Lamp
ON
(Normal)
283 W
ON
(Eco)
234 W
Standby
(Network)
ON 2.9 W
OFF 0.36 W
220-240V
Area
(Europe,
etc.)
Lamp
ON
(Normal)
270 W
ON
(Eco)
223 W
Standby
(Network)
ON 3.3 W
OFF 0.47 W
Rated Voltage & Current 100 - 240 V AC 50/60 Hz 2.9 - 1.3 A
Size
Excluding feet
Unit:
mm
228 (D) x 295 (W) x 77 (H)
Maximum Dimension 228 (D) x 295 (W) x 79 (H)
Weight Approx. 2.3 kg/5.1 lbs
Fan noise
Normal mode 37 dB
Eco mode 29 dB
Model
EB-
S01
EB-
W01
EB-
X14G
EB-
S11
EB-
X11
EB-
S02
EB-
S02H
EB-
X02
EB-
W02
EB-
S12
EB-
S12H
EB-
X12
EB-
W12
EB-
X14
EH-
TW480
Item

Epson EB-X11 Specifications

General

Matrix size	0.55 \
Projection distance	1.8 - 2.17 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	295 x 228 x 77 mm
Connectivity technology	Wired
F-number (relative aperture)	1.58
Focus	Manual
Offset	8:1 %
Throw ratio	1.48 - 1.77:1
Optical zoom	1.2 x
Focal length range	16.9 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	2
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1024 x 768 (XGA), 1920 x 1080 (HD 1080)
RMS rated power	2 W
Image formats supported	BMP, GIF, JPG, PNG
Noise level	37 dB
Preset modes	Cinema, Dynamic, Presentation, sRGB
Country of origin	China
Noise level (economic mode)	29 dB
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2178 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	358 mm
Package width	357 mm
Package height	156 mm
Package weight	3500 g
