Epson EB-X11 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 48 Revision C
CN1105
RS Board
(EB-S11/X11
only)
--- ---
When pressing the power button, initialization starts normally, then the projection starts. But
the RS-232 cannot be used.
"Troubleshooting on Operation
Abnormality (p.41)"
CN1200 TH Board (1)
SE Sensor error
Sensor error occurs while initializing, and LEDs indicate the error, then the projector turns
into the abnormal stand-by status.
"Troubleshooting from the Error
Code on Cooling System Errors
(p.35)"
CN1201 TH Board (2)
CN1203 INT Fan
FN Fan error
Fan error occurs while initializing and LEDs indicate the error, then the projector turns into
the abnormal stand-by status.
CN1205 EX Fan
CN1206 Lamp Fan
CN3301 Speaker --- ---
When pressing the power button, initialization starts normally, then the projection starts.
Audio controller on screen display appears, but no sound is output from the speaker even if
the audio input is applied.
"TroubleShooting on Audio
Input/Output (p.40)"
Connector
No.
Destination
Error Information
Status Reference
Code Name

Epson EB-X11 Specifications

General

Matrix size	0.55 \
Projection distance	1.8 - 2.17 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	295 x 228 x 77 mm
Connectivity technology	Wired
F-number (relative aperture)	1.58
Focus	Manual
Offset	8:1 %
Throw ratio	1.48 - 1.77:1
Optical zoom	1.2 x
Focal length range	16.9 - 20.28 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	2
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1024 x 768 (XGA), 1920 x 1080 (HD 1080)
RMS rated power	2 W
Image formats supported	BMP, GIF, JPG, PNG
Noise level	37 dB
Preset modes	Cinema, Dynamic, Presentation, sRGB
Country of origin	China
Noise level (economic mode)	29 dB
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2178 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	358 mm
Package width	357 mm
Package height	156 mm
Package weight	3500 g
