Saving settings to a computer
a
Disconnect the power cord from the projector, and check that all
of the projector's indicators have turned off.
b
Connect the computer's USB port to the projector's USB-B port
with a USB cable.
c
While holding down the [Esc] button, connect the power cord to
the projector.
When the projector's indicators turn on as follows, release the [Esc]
button.
Power: Blue - On/Status: Blue - On/Lamp: Orange - On/Temp: Orange - On
The projector is recognized as a removable disk by the computer.
d
Open the removable disk, and save the batch setup file
(PJCONFDATA.bin) to the computer.
a
If you need to change the name of the batch setup file, add text
after PJCONFDATA. If you change the PJCONFDATA section
of the file name, the projector may not be able to recognize the
file correctly.
e
Perform "Remove USB device" on your computer, and then
disconnect the USB cable.
a
When using OS X, perform "Remove EPSON_PJ".
The projector enters standby status.
Performing Batch Setup for Multiple Projectors
124

Epson EB-X27 Specifications

General

Projection Technology	3LCD
Resolution	XGA (1024 x 768)
Contrast Ratio	10, 000:1
Zoom Ratio	1.2x
Throw Ratio	1.48 - 1.77:1
Projection Size	30 - 300 inches
Brightness	2700 lumens
Lamp Life	10, 000 hours (ECO mode)
Keystone Correction	Vertical: ±30 degrees
Inputs	HDMI, VGA, Composite, USB Type A, USB Type B
Dimensions	297 mm x 234 mm x 77 mm
