Epson EB-X27 User Manual

EB-S29/EB-S27
EB-955WH/EB-950WH/EB-965H
/EB-945H/EB-940H/EB-98H
/EB-97H/EB-W29/EB-X30
/EB-X29/EB-X27
Adjusting the Image Position
Press the foot adjust lever to extend the front adjustable foot. You can
adjust the position of the image by tilting the projector up to 12 degrees.
a
The larger the angle of tilt, the harder it becomes to focus. Install the
projector so that it only needs to be tilted at a small angle.
Adjusting the Horizontal Tilt
Extend and retract the rear feet to adjust the projector's horizontal tilt.
A
Extend the rear foot.
B
Retract the rear foot.
Correcting the Focus
You can correct the focus using the focus ring.
EB-S29/EB-S27
EB-955WH/EB-950WH/EB-965H
/EB-945H/EB-940H/EB-98H
/EB-97H/EB-W29/EB-X30
/EB-X29/EB-X27
Adjusting Projected Images
52

Epson EB-X27 Specifications

General

Projection Technology	3LCD
Resolution	XGA (1024 x 768)
Contrast Ratio	10, 000:1
Zoom Ratio	1.2x
Throw Ratio	1.48 - 1.77:1
Projection Size	30 - 300 inches
Brightness	2700 lumens
Lamp Life	10, 000 hours (ECO mode)
Keystone Correction	Vertical: ±30 degrees
Inputs	HDMI, VGA, Composite, USB Type A, USB Type B
Dimensions	297 mm x 234 mm x 77 mm
