Epson EB-X27 User Manual

Connecting External Equipment
You can output images and audio by connecting an external monitor or speaker.
You can also output microphone audio from the projector's speaker by connecting a microphone.
A
When outputting images to an external monitor
Connect the external monitor to the projector's Monitor Out port using the cable supplied with the external monitor.
B
When outputting audio to an external speaker
Connect the external speaker to the projector's Audio Out port using a commercially available audio cable.
C
When outputting microphone audio (EB-955WH/EB-950WH/EB-965H/EB-945H/EB-940H/EB-98H/EB-97H only)
Connect the microphone to the projector's Mic port. When using a condenser microphone, set Plug-in Power to On.
s Extended - A/V Settings - Plug-in Power p.106
Connecting Equipment
33

Epson EB-X27 Specifications

General

Projection Technology	3LCD
Resolution	XGA (1024 x 768)
Contrast Ratio	10, 000:1
Zoom Ratio	1.2x
Throw Ratio	1.48 - 1.77:1
Projection Size	30 - 300 inches
Brightness	2700 lumens
Lamp Life	10, 000 hours (ECO mode)
Keystone Correction	Vertical: ±30 degrees
Inputs	HDMI, VGA, Composite, USB Type A, USB Type B
Dimensions	297 mm x 234 mm x 77 mm
