Name Function
H
Audio1 port
Inputs audio from equipment connected to the
Computer1 port.
I
Audio Out port
Outputs audio from the currently projected image to an
external speaker.
J
Audio2 port
Inputs audio from equipment connected to the
Computer2 port.
K
Remote receiver
Receives signals from the remote control.
L
Speaker
Outputs audio.
M
Computer1 port
Inputs image signals from a computer and component
video signals from other video sources.
N
Computer2 port
O
HDMI2/MHL port
(EB-955WH/
EB-950WH/EB-965H/
EB-945H/EB-940H/
EB-98H/EB-97H only)
• Inputs video signals from HDMI compatible video
equipment and computers. This projector is compatible
with
HDCP
g
.
• Inputs signals from smartphones and tablet devices that
support
MHL
g
(Mobile High-definition Link).
s "Connecting Equipment" p.28
P
HDMI1 port
(EB-955WH/
EB-950WH/EB-965H/
EB-945H/EB-940H/
EB-98H/EB-97H only)
HDMI port
(EB-W29/EB-X30/EB-
X29/EB-X27/EB-S29/
EB-S27 only)
Inputs video signals from HDMI compatible video
equipment and computers. This projector is compatible
with
HDCP
g
.
Q
LAN port
(Except for EB-S29/EB-
S27)
Connects a LAN cable to connect to a network.
Name Function
R
USB-B port
• Connects the projector to a computer using a USB cable,
and projects the images on the computer.
s
"Projecting with USB Display" p.43
• Connects the projector to a computer using a USB cable
to use the Wireless Mouse function.
s "Using the Remote Control to Operate the
Mouse Pointer (Wireless Mouse)" p.74
S
USB-A port
• Connects a USB storage device or a digital camera, and
projects images using PC Free.
s "Projecting Without a Computer (PC Free)"
p.63
• Connects the optional Document Camera.
• Connects the optional Wireless LAN unit.
s "Installing the Wireless LAN Unit" p.36
• Connects the optional Quick Wireless Connection USB
Key.
s "Installing the Quick Wireless Connection USB
Key" p.37
T
Wireless LAN unit
fixing screw
This screw secures the wireless LAN unit cover.
Part Names and Functions
15
