Component Video

Units: dots

Signal

Refresh Rate

(Hz)

Resolution

Aspect Mode

4:3 16:9

SDTV(480i) 60 720x480 800x600 800x450

SDTV(576i) 50 720x576 800x600 800x450

SDTV(480p) 60 720x480 800x600 800x450

SDTV(576p) 50 720x576 800x600 800x450

HDTV(720p) 50/60 1280x720 800x600 800x450

HDTV(1080i) 50/60 1920x1080 800x600 800x450

Composite video/S-video

Units: dots

Signal

Refresh Rate

(Hz)

Resolution

Aspect Mode

4:3 16:9

TV(NTSC) 60 720x480 800x600 800x450

TV(PAL,SECAM) 50 720x576 800x600 800x450
