Epson L210 Service Manual

Confidential
Troubleshooting Fatal Error Code List 14
L350/L300/L355/L210/L110 Series Revision B
DC motor
error
F3H PF PID reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Sensor failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
• Paper jam
• Paper is pulled out from the ASF side when paper is fed
• Main Board failure (Motor driver failure)
F4H PF PID lock error
• PF Encoder failure (contaminated/detached scale, Encoder Sensor failure)
• PF Motor failure
• PF drive mechanism overload (paper jam, foreign object, insufficient
grease, deformation of the Main Frame)
• Cable disconnection
• Main Board failure (Motor driver failure)
F8H PF load position reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Sensor failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
F9H PF load position excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Sensor failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
• Main Board failure (Motor driver failure)
FAH PF load position excess load error
• PF Motor failure
• PF drive mechanism overload (paper jam, foreign object)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
• Cable disconnection
FCH PF load position error
• PF Encoder failure (contaminated/detached scale, Encoder Sensor failure)
• PF Motor failure
• PF drive mechanism overload (paper jam, foreign object)
• Cable disconnection
Motor drive
time error
D1H CR (PID) driving time error • Main Board failure (Firmware failure)
D2H CR (load position) driving time error
• Change Lever failure
• CR Motor failure
• Main Board failure (Motor driver failure)
D3H PF (PID) driving time error • Main Board failure (Firmware failure)
D4H PF (BS) driving time error
• Change Lever failure
• CR Motor failure
• Main Board failure (Motor driver failure)
Printhead
system error
40H Transistor temperature error • Main Board failure
41H X-Hot detect error (pre printing)
• Printhead failure
• Main Board failure
42H X-Hot detect error (after flushing)
43H Head temperature error
Sequence
error
50H Home position error
• Foreign object
• Deformation of the Main Frame
• Change Lever failure
• Paper jam
56H
Contact error at ink replacement timing
(Power-off)
• Foreign object
• Ink Cartridges are not installed correctly
• Paper jam
Sequence
error
5BH Insoluble paper jam error
• Foreign object
• Deformation of the Main Frame
• Change Lever failure
• Paper jam
Circuit error 80H Circuit error (include blowout of a fuse) • Main Board failure
Table 1-3. Fatal Error List (Printer)
Error type
Error
code
Error name Possible cause

Epson L210 Specifications

General

Functions	Print, Scan, Copy
Print Resolution	5760 x 1440 dpi
Scanner Type	Flatbed color image scanner
Scanner Resolution	600 x 1200 dpi
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Print Technology	On-demand inkjet
Paper Capacity	50 sheets
Ink Type	Dye Ink
Print Speed (Black)	27 ppm
Print Speed (Color)	15 ppm
Copy Resolution	600 x 600 dpi
Paper Sizes	A4, A5, A6, B5, DL
Ink Tank Capacity	70 ml (each color)
Operating System Compatibility	Windows XP/Vista/7/8, Mac OS X 10.6.8 or later
Dimensions (W x D x H)	472 x 300 x 145 mm
