Epson L210 Service Manual

Confidential
Adjustment Mechanism Adjustment / Check 60
L350/L300/L355/L210/L110 Series Revision B
3.3 Mechanism Adjustment / Check
This section provides the procedure for the mechanism adjustment and check.
3.3.1 Checking the Platen Gap
This section describes the procedure for checking the platen gap (PG).
 Tools

Thickness gauge: 1.5 mm (x2), 2.0 mm (x2)
 Confirmation procedure
 This printer does not have any PG adjustment mechanism, however, it is designed so that the
platen gap can fall within the expected range if you correctly reassemble the unit (including
using the Epson-specified jigs) according to this manual. If the PG cannot fall within the
standard range after performing the platen gap check described in this section, first check if
the unit is correctly reassembled following the instructions in this manual. Even if the unit is
correctly reassembled but the PG still cannot fall within the standard range, replace the unit
with a new/refurbished one.
 The standard range of the PG is as follows:
• Standard: 1.75 ± 0.25 mm
When checking the PG, make sure of the following.
 Check the PG with new ink cartridges installed to the CR Unit, and also with all parts
related to the PG installed to the printer (p 53).
 Move the CR Unit by pulling the CR Timing Belt.
 Be careful not to damage the nozzles of the Printhead with the thickness gauge.

Epson L210 Specifications

General

Functions	Print, Scan, Copy
Print Resolution	5760 x 1440 dpi
Scanner Type	Flatbed color image scanner
Scanner Resolution	600 x 1200 dpi
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Print Technology	On-demand inkjet
Paper Capacity	50 sheets
Ink Type	Dye Ink
Print Speed (Black)	27 ppm
Print Speed (Color)	15 ppm
Copy Resolution	600 x 600 dpi
Paper Sizes	A4, A5, A6, B5, DL
Ink Tank Capacity	70 ml (each color)
Operating System Compatibility	Windows XP/Vista/7/8, Mac OS X 10.6.8 or later
Dimensions (W x D x H)	472 x 300 x 145 mm
