Epson L210 Service Manual

Confidential
Appendix Points to be checked before packing the printer 73
L350/L300/L355/L210/L110 Series Revision B
5.2 Points to be checked before packing the printer
 Attaching the Air Release Hole Caps
To prevent the ventilation film from getting wet, attach the Air Release Hole Caps to the air release holes of the Ink
Supply Tank Assy.
Figure 5-2. Attaching the Air Release Hole Caps

The Valve Lever is on the position shown below (the
Choke Valve is closed). (See Figure 2-10.)
 All the caps of the Ink Supply Tank Assy are securely
closed.
 The hooks (x2) of the Ink Supply Tank Assy are
securely engaged with the Housing Right.
 The opened ink bottle is not included in the box.
Ink Supply Tank Assy
Air Release Hole Cap
Air Release Hole Cap
Air release hole
Valve Lever
Cap
Ink Supply
Tank Assy
Housing Right

Epson L210 Specifications

General

Functions	Print, Scan, Copy
Print Resolution	5760 x 1440 dpi
Scanner Type	Flatbed color image scanner
Scanner Resolution	600 x 1200 dpi
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Print Technology	On-demand inkjet
Paper Capacity	50 sheets
Ink Type	Dye Ink
Print Speed (Black)	27 ppm
Print Speed (Color)	15 ppm
Copy Resolution	600 x 600 dpi
Paper Sizes	A4, A5, A6, B5, DL
Ink Tank Capacity	70 ml (each color)
Operating System Compatibility	Windows XP/Vista/7/8, Mac OS X 10.6.8 or later
Dimensions (W x D x H)	472 x 300 x 145 mm
