Epson L220 Service Manual

Confidential
Disassembly/Reassembly Disassembly/Reassembly Procedures 32
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
2.2.1 Disassembly Flowchart
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series described in this manual have differences in
their structure because the same printer mechanism is used for some of them and the composition of housings or
functions differs.
The functions and differences according to the models are as follows.
Therefore, parts and units are colored and classified into 5 types in the flowchart given in this section.

Common parts/unit: Black
 L365/L366,L360/L362,L220/L222 Series: Blue
 L365/L366 Series: Red
 L310/L312,L130/L132 Series: Green
 L220/L222,L130/L132 Series: Orange
Table 2-2. Function List According to Models
Item
L365/L366
Series
L360/L362
Series
L220/L222
Series
L310/L312
Series
L130/L132
Series
Scanner O O O --- ---
Panel
Movable type O --- --- --- ---
Locked type --- O O --- ---
Button type --- --- --- O O
Wireless LAN O --- --- --- ---
Low cost parts --- --- O --- O
Disassembly Flowchart Start Position p 33 p 33 p 33 p 34 p 34
Table 2-3. Components According to Functions
Item Specification
Scanner
The shape and unit of components below differ due to the difference of specifications of Scanner Unit.
• Scanner Unit
•Hinge
• Housing Rear/Left/Right
•Main Board
• Shield Plate
Panel
The shape and unit of components below differ due to the difference of specifications of Panel Unit.
•Panel Unit
Wireless LAN
The following part is not mounted on the models without the Wireless LAN.
• Wireless LAN Module
Low cost parts
• CR Timing Belt
• CR Motor
•PF Motor
• Housings, others

Epson L220 Specifications

General

Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (ISO/IEC 24734) mono	7 ipm
Print speed (ISO/IEC 24734) color	3.5 ipm
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	15 ppm
Scanner type	-
Scan speed (black)	2.4 ppm
Scan speed (color)	9.5 ppm
Image formats supported	BMP, JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 1200 DPI
Maximum copy resolution	- DPI
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Philippines
Maximum duty cycle	- pages per month
Product color	Black
Built-in display	No
Market positioning	Home & office
Paper input type	Paper tray
Total input capacity	- sheets
Total output capacity	30 sheets
Total number of input trays	1
Envelopes sizes	10, C6, DL
Photo paper sizes	10x15, 13x18 cm
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (ready)	3.8 W
Power consumption (sleep)	0.8 W
Power consumption (copying)	12 W
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Yes
Standard interfaces	USB
Internal memory	- MB
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	50 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	5 pc(s)
Package depth	535 mm
Package width	390 mm
Package height	210 mm
Package weight	5960 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	300 mm
Width	482 mm
Height	145 mm
