Epson L350 Service Manual

Confidential
Disassembly/Reassembly Overview 23
L350/L300/L355/L210/L110 Series Revision B
Panel Unit 4:21 --- 4:21
Panel Housing Lower Assy 5:02 --- 5:02
Panel Board Assy 5:21 --- 5:21
Panel Bottons 5:37 --- 5:37
Panel Housing Upper Assy
5:37 --- 5:37
CR Scale
4:06 --- 4:06
LD Roller Cover 4:03 --- 4:03
LD Roller Assy
5:29 0:47 6:16
Hopper
4:06 6:03 10:09
FFC Holder MB 4:45 --- 4:45
Shield Plate 7:56 --- 7:56
PE Sensor Lever
9:26 0:47 10:13
Main Board
EEPROM Data Copy OK 8:37 1:10 9:47
EEPROM Data Copy NG 8:37 27:58 36:35
CR Motor
8:44 1:00 9:44
CR Driven Pulley Assy 3:49 3:07 6:56
Main Frame Assy 7:15 11:16 18:31
Paper GuideUpper Assy
9:20 7:21 16:41
CR Unit
12:52 9:52 22:44
CR Timing Belt
12:31 0:40 13:11
CR Encoder Sensor 13:13 --- 13:13
Head FFC
14:19 --- 14:19
FFC Holder 13:51 --- 13:51
Frame Base Assy 8:07 8:51 16:58
Pump Unit
9:53 --- 9:53
PF Grounding Spring 10:12 --- 10:12
Spur Gear 16.5 10:21 --- 10:21
PF Roller Unit
13:11 5:51 19:02
PF Motor Assy
11:43 1:08 12:51
Frame Base 11:43 6:53 18:36
Tube Cover 0:22 --- 0:22
Ink Supply Tank Assy 4:57 --- 4:57
Top Cover
0:10 --- 0:10
Bottom Cover
1:44 --- 1:44
Left Cover
2:34 --- 2:34
Right Cover
2:07 --- 2:07
Ink Supply Tank (Magenta)
4:11 --- 4:11
Ink Supply Tank (Yellow)
4:11 --- 4:11
Ink Supply Tank (Cyan)
4:11 --- 4:11
Ink Supply Tank (Black)
4:11 --- 4:11
Valve Lever
0:19 --- 0:19
Cap Tank
0:22 --- 0:22
Tube Valve Holder Front
0:55 --- 0:55
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson L350 Specifications

General

Print Technology	Inkjet
Print Method	On-demand inkjet (Piezoelectric)
Print Resolution	5760 x 1440 dpi
Minimum Ink Droplet Size	3 pl
Functions	Print, Copy, Scan
Scanner Type	Flatbed color image scanner
Output Tray Capacity	30 sheets
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Ink Tank System	Integrated Ink Tank System
Print Speed (Black)	33 ppm
Print Speed (Color)	15 ppm
Scan Resolution	600 x 1200 dpi
Paper Sizes	A4, A5, A6, B5, Letter, Legal, DL
Input Tray Capacity	100 sheets
Operating System Compatibility	Windows XP, Windows 7, Windows 8, Windows Vista, Mac OS X 10.5.8 or later
Dimensions	472 x 300 x 145 mm
