Epson L350 Service Manual

Confidential
Disassembly/Reassembly Overview 24
L350/L300/L355/L210/L110 Series Revision B
Tube Valve Holder Rear 1:06 --- 1:06
Ink Supply Tank Tube Assy
3:30 --- 3:30
Cover Joint
2:39 --- 2:39
Ink Supply Tube Guide 1st
0:06 --- 0:06
Ink Supply Tube Guide 2nd
3:25 --- 3:25
Joint
2:20 --- 2:20
Tube Pressing Plate
0:52 --- 0:52
Ink Supply Tube Assy
2:11 --- 2:11
Adapter
1:49 --- 1:49
Tube Guide Sheet
1:39 --- 1:39
Tube Guide Sheet Sub
0:30 --- 0:30
Adapter Cover
0:37 --- 0:37
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson L350 Specifications

General

Print Technology	Inkjet
Print Method	On-demand inkjet (Piezoelectric)
Print Resolution	5760 x 1440 dpi
Minimum Ink Droplet Size	3 pl
Functions	Print, Copy, Scan
Scanner Type	Flatbed color image scanner
Output Tray Capacity	30 sheets
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Ink Tank System	Integrated Ink Tank System
Print Speed (Black)	33 ppm
Print Speed (Color)	15 ppm
Scan Resolution	600 x 1200 dpi
Paper Sizes	A4, A5, A6, B5, Letter, Legal, DL
Input Tray Capacity	100 sheets
Operating System Compatibility	Windows XP, Windows 7, Windows 8, Windows Vista, Mac OS X 10.5.8 or later
Dimensions	472 x 300 x 145 mm
