Epson LabelWorks LW-600P Quick Start Guide

12 | Using the Label Editor Software
■ To add a symbol, click the Symbol
icon and select a symbol from one of
the categories, then click OK. Click
the location where you want the
symbol to appear.
■ To change the font and size, select the
text box, then use the Font Name and
Font Size selection boxes. You can use
any font installed on your computer.
4. When you’re ready to print, click the
Print icon. Click Printer Settings to
choose additional options. Select the
number of copies, then click OK to print.
Note: The Label Editor software includes many
additional features and label formatting
options. See the online User’s Guide for more
information.
Creating labels in Mac OS X
Once your LabelWorks printer is connected
to your Mac, you can use the Label Editor
Lite software to design your labels or
ribbons.
1. Start the Label Editor Lite software. You
see a screen like this:
Print icon
Label design icons

Epson LabelWorks LW-600P Specifications

General

Color	No
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	180 x 180 DPI
Built-in barcodes	Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Sustainability certificates	ENERGY STAR
Product color	Black, Grey
Connectivity technology	Wired & Wireless
Pallet width	800 mm
Pallet height	710 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	210 pc(s)
Minimum order quantity	5 pc(s)
Quantity per pallet (UK)	280 pc(s)
Quantity per pallet layer	25 pc(s)
Quantity per pallet layer (UK)	40 pc(s)
Package depth	263 mm
Package width	202 mm
Package height	85 mm
Package weight	1269 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	132 mm
Width	54 mm
Height	146 mm
Weight	440 g
