This Quick Reference card gives brief instructions on connecting your
PowerLite projector and using common features. For details, see the
online User’s Guide.
Remote Control Map
Turn the projector on
Turn the projector off
Illuminate buttons temporarily
Replacement Parts
Product Part number
Replacement lamp (ELPLP77) V13H010L77
Air filter (ELPAF45) V13H134A45
You can purchase replacement parts from an Epson
authorized reseller. See “Where to Get Help” inside this card
for more information.
Select a source
Automatically adjust computer
Change the aspect ratio
Display a test pattern
Freeze the image
Open projector menus
Navigate through menu settings;
move pointer
Select menu settings; left
mouse button
Activate split screen
Move to next or previous
image when projecting from a
computer over the network
Control volume
Open menus assigned by user
Use numeric keys to enter
passwords, IP settings, etc.
Hold down and use numeric keys
to select projector to control
Control one or all projectors
Port to connect
remote control cable
Switch image sources
Select color modes
Temporarily turn off display and
audio
Cancel current operation or return
to previous menu; right mouse
button
Reset menu settings to their
default value
Hold down and use numeric keys
to enter numbers
Display on-screen help
Zoom in or out on part of an
Stereo mini jack cable
VGA cable
HDMI cable
5BNC-to-VGA cable
S-Video cable
RCA audio cable
BNC-to-component cable
DisplayPort cable
Video cable
Ethernet cable
5BNC-to-VGA cable
BNC-to-component cable
VGA-to-component
cable
S-Video cable
RCA audio cable
Ethernet cable
Stereo mini jack cable
VGA cable
HDMI cable
DisplayPort cable
Video cable
PowerLite 4650/
4750W/4770W
PowerLite 4855WU
VGA cable
VGA cable
VGA-to-component
cable
Stereo mini jack cable
Stereo mini jack cable
