Epson PowerLite EB-L210SF User Manual

162
5. Select the area you want to adjust and press Enter.
Note: The area you selected is displayed in orange. Adjust overlapping areas starting with the
brightest areas first. For example, adjust area 2 to match area 1, then adjust area 3 to match area 2.
6. Adjust the brightness and tone of the areas that do not overlap to match the areas that overlap using
the displayed adjustment sliders. Then press the Esc button.
7. Repeat the previous two steps as needed until all areas match.
8. If the tone of some areas do not match, you can adjust them using the Area Correction setting.
Continue with the next step. Otherwise, press the Menu button to exit.
9. Press the Esc button to return to the Black Level screen.
10. Select the Area Correction setting and press Enter.

Epson PowerLite EB-L210SF Specifications

General

DVI port	No
Microphone in	Yes
Audio (L/R) in	1
Composite video in	-
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Matrix size	0.62 \
Heat dissipation	884 BTU/h
Number of colors	1.07 billion colors
White light output	4000 ANSI lumens
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (dynamic)	2500000:1
Screen size compatibility	55 - 125 \
Keystone correction, horizontal	-15 - 15 °
Video color modes	Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB
Supported video modes	1080p
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	27 dB
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Color depth	10 bit
Focus	Manual
Throw ratio	0.45 - 0.61:1
Placement	Ceiling, Desktop, Wall
Product type	Short throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Cord length	1.8 m
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	201 W
Power consumption (economy mode)	191 W
RMS rated power	16 W
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	337 mm
Width	325 mm
Height	90 mm
Weight	4600 g
