Part Names and Functions
Base
Air filter (air intake vent)
This prevents dust and other foreign particles
from getting inside the projector when air is
drawn in. It should be cleaned and replaced
periodically.
Suspension bracket fixing points (3 points)
Attach the optional ceiling mount here when suspending the projector from a ceiling.
Front adjustable footFoot adjust lever
Air intake vent
Clean the air intake vent
periodically.
