Epson PowerLite S4 User Manual

21
Functions for Enhancing Projection
Displaying the Pointer
This allows you to move a pointer icon on the projected image, and helps you
draw attention to the area you are talking about.
1 Display the pointer.
Each time you press the button the pointer appears or disappears.
2 Move the pointer icon.
Enlarging Part of the Image (E-Zoom)
This is useful when you want to see images in greater detail, such as graphs
and details in a table.
1 Start E-Zoom.
Remote control
Pointer icon
Remote control
p
You can use the "Pointer Shape" command in the "Settings" menu to
change the shape of the pointer to one of three different shapes. See page
34.
Remote control

Epson PowerLite S4 Specifications

General

Number of colors	16.78 million colors
Projection distance	6 m
Vertical scan range	48 - 85 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	16.6 mm
Interface	USB
Audio input	RCA x 2
Dimensions (WxDxH)	246 x 328 x 100 mm
Power requirements	100-240 V +/- 10%, 50/60 Hz AC
Connectivity technology	Wired
Noise level	36 dB
Dot clock scanning frequency	162 MHz
RMS rated power	1 W
Number of built-in speakers	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	5 W
Power consumption (typical)	250 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	2600 g
