Epson Pro G7000W User Manual

105
9. Press the Esc button to return to the Curved Surface menu screen.
10. Repeat the previous three steps as necessary to adjust other image areas.
If the image expands or contracts, continue with the next step to adjust the linearity.
11. Select one of the following from the Curved Surface menu screen:
• Horizontal Linearity: Adjusts horizontal expansion or contraction.
• Vertical Linearity: Adjusts vertical expansion or contraction.
12. Select a displayed line to use as a baseline and press Enter.
The selected baseline flashes red and white.
13. Adjust the linearity by doing one of the following:
• Press the left arrow button to contract the distance between the lines closest to the baseline.
• Press the right arrow button to expand the distance between the lines closest to the baseline.
14. When you are finished, press the Menu button.
Note: If necessary, you can fine-tune the results of your Curved Surface adjustments using Point
Correction.
Parent topic: Image Shape

Epson Pro G7000W Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.27 - 7.62 m
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10, 16:9
Screen size compatibility	- \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-45 - 45 °
Keystone correction, horizontal	-30 - 30 °
Lamp type	UHE
Lamp power	400 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Noise level	37 dB
Noise reduction	Yes
Noise level (economic mode)	31 dB
Dot clock scanning frequency	162 MHz
Throw ratio	1.44 - 2.32:1
Optical zoom	1.6 x
Focal length range	24 - 38.2 mm
Aperture range (F-F)	1.7 - 2.3
Vertical lens shift range	-67 - 67 °
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 1024 (SXGA)
Operating temperature (T-T)	0 - 45 °C
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	White
Cable lock slot type	Kensington
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Audio (L/R) in	3
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Remote control type	Wired
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	540 W
Power consumption (economy mode)	498 W
Built-in display	-

Weight and Dimensions

Depth	382 mm
Width	505 mm
Height	144 mm
Weight	12880 g
