Epson SC-R5070L - Specifications Table

Specifications Table
Printer Specifications
Printing method On-demand ink jet
Nozzle configuration
Except for LM and LC 400 nozzles x 2 x 2 rows x 5
colors (Black, Cyan, Magenta,
Yellow, Optimizer)
LM, LC 400 nozzles x 2 x 1 rows x 2
colors (Light Magenta, Light
Cyan)
Resolution (maximum) 1200 × 2400 dpi
Print resolution equivalent to
600 x 600 x 8 Half Tone layers
Control code ESC/P raster (undisclosed
command)
Media feed method Friction feed method
Built-in memory 2 GB
Interface Hi-Speed USB-Compatible
with the USB 2.0 Specification.
100Base-TX/1000Base-T
*1
Rated voltage (input)
#1, #2 AC200-240 V
Ink unit
*2
AC100-240 V
Rated voltage (output)
#3 AC200-240 V
Rated frequency (input)
#1, #2 50/60 Hz
Ink Unit 50/60 Hz
Rated frequency (output)
#3 50/60 Hz
Rated current (input)
#1, #2 16 A
Ink Unit 1.4 A
Rated current (output)
Printer Specifications
#3 1.4 A
Power consumption
SC-R5000 Series
(total for numbers
#1 and #2)
Printing: Approx. 4.6 kW
Sleep mode: Approx. 44.0 W
Power off: Approx. 1.0 W
SC-R5000L Series
(total for numbers
#1 and #2)
Printing: Approx. 4.6 kW
Sleep mode: Approx. 46.0 W
Power off: Approx. 1.1 W
Temperature and humidity (without condensation)
Recommended 20 to 25°C (68 to 77°F), 40 to
60%
In use 15 to 30°C (59 to 86°F), 20 to
80%
During storage
(before unpacking)
-20 to 60°C (-4 to 140°F)
(within 120 hours at 60°C
[140°F], within a month at 40°C
[104°F]), 5 to 85%
During storage
*3
(after unpacking)
-20 to 40°C (-4 to 104°F)
(within a month at 40°C
[104°F]), 5 to 85%
Temperature and humidity range
Gray area: When in use
Diagonal line area: Recommended
Dimension
Storage dimensions 2949 (W) x 1045 (D) x 1605 (H)
mm
(116.1 [W] x 41.1 [D] x 63.2 [H]
inches)
Maximum
dimensions
2949 (W) x 1045 (D) x 1774 (H)
mm
(116.1 [W] x 41.1 [D] x 69.5 [H]
inches)
Weight
*4
SC-R5000 Series/SC-R5000L Series User's Guide
Appendix
141
