Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
PRODUCT DESCRIPTION Basic Specifications 26
Confidential
1.2.6 Auto Take-up Reel Unit
Item Specified values
Paper Width 406 to 1,118 mm
Paper length
2-inch core: 1.3 to 40 m
3-inch core: 1.6 to 30.5 m
Rotation speed Max. 40 rpm
Weight 6.9 kg
Environment
Temperature: 10 to 35 °C
Humidity: 20 to 80%
Rated voltage AC 100 to 240 V
Input voltage range AV 90 to 264 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.2 A
Power consumption
Approx. 9 W
Approx. 3 W in Ready Mode

Table of Contents

Other manuals for Epson Stylus Pro 9900

Questions and Answers:

Epson Stylus Pro 9900 Specifications

General IconGeneral
ColorYes
Maximum resolution2880 x 1440 DPI
Media thickness0.08 - 1.50 mm
Maximum print sizeA0 (841 x 1189 mm)
Maximum roll width1118 mm
DisplayLCD
Internal memory64 MB
Country of originChina
Drive device, buffer size256 MB
Sound pressure level (printing)50 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet interface typeFast Ethernet
Compatible operating systemsMicrosoft Windows 2000, XP, XP 64-bit, Vista, MAC OSX 10.x.x
Power requirementsAC 100-240V 50/60Hz
Power consumption (active)80 W
Power consumption (standby)1 W
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 85 %
Operating relative humidity (H-H)20 - 80 %
Package depth2040 mm
Package width815 mm
Package height1080 mm
Package weight193053 g
Quantity per pack1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1702 x 678 x 1196 mm
