Epson Stylus Pro 9900 Service Manual

Epson Stylus Pro 7700/7710/7700M/7710M/7900/7910/9700/9710/9900/9910/WT7900/WT7910/9890/9908/7890/7908 Revision I
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 300
Confidential
4.4.6.11 Ink Selector
INK DISCHARGE
1. Turn the printer ON in the Serviceman Mode.
Turn the power ON while pressing [Menu ], [PaperFeed ], and [OK].
2. Select SELF TESTING → Maintenance→ Selector Exchange→Sequence.
3. Press the [OK] button.
4. Remove all the ink cartridges, and install the drain cartridges to all the ink slots.
5. Press the [OK] button to discharge ink.
6. Turn the printer OFF when [Press] Power Button is displayed.
C A U T I O N
When disassembling this part, be sure to discharge ink in advance
following the procedure below.
C H E C K
P O I N T
Because Epson Stylus Pro 7700/7710/9700/9710 does not have the
Selector Exchange menu, select the Tube Exchange menu instead.
C H E C K
P O I N T
After discharging ink, the initial charge flag is automatically set.
The next time turning the power on, the initial ink charge sequence
starts.

Epson Stylus Pro 9900 Specifications

General

Color	Yes
Maximum resolution	2880 x 1440 DPI
Media thickness	0.08 - 1.50 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll width	1118 mm
Display	LCD
Internal memory	64 MB
Country of origin	China
Drive device, buffer size	256 MB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Fast Ethernet
Compatible operating systems	Microsoft Windows 2000, XP, XP 64-bit, Vista, MAC OSX 10.x.x
Power requirements	AC 100-240V 50/60Hz
Power consumption (active)	80 W
Power consumption (standby)	1 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	2040 mm
Package width	815 mm
Package height	1080 mm
Package weight	193053 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Dimensions (WxDxH)	1702 x 678 x 1196 mm
