Epson TM-C3500 Series - SAP GLM Setting

Chapter 2 Setting Up the Printing Environment
28
SAP GLM Setting
MeasurethelabeldimensionsfortheMediatypeused,andsettoSAPGLM[EditLabel
Stock]‐[Attributes].
Die-cut label paper
Media type Ref.
Die-cut label paper page 28
Die-cut label paper (with black mark) page 29
Continuous paper, all-surface label paper page 30
Symbols Function Parameter
A Label Stock Width 30 to 112 mm (1.18 to 4.41 inch)
B Label Stock Height 8 to 1016 mm (0.31 to 40.00 inch)
C Distance from Edge: Left 0 to 112 mm (0 to 4.41 inch)
D Distance from Edge: Top 0 to 1016 mm (0 to 40.00 inch)
Print Area
A
D
B
C
