14 TM-L500A User’s Manual
English
Specifications
Mbps: megabits per second
Printing method Thermal line
Paper
dimensions
Boarding pass Width: 82.5 ± 0.5 or 79.5 ± 0.5 mm
Length: 203.2 ± 0.38 and 187.325 mm
Thickness: 75 ~ 200 µm
Baggage tag Width: 54 ± 0.5 mm or 50.8 ± 0.5 mm
Length: 400 ~ 600 mm
Thickness: 220 µm or less
Interface Serial (RS-232)/Ethernet (10BASE-T/100BASE-TX)/
USB [Compliance: USB 2.0, Communication speed: Full-speed (12 Mbps)]
Power supply AC adapter (Model: M159B [PS-180])
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: –20 to 50°C {-4 to 122°F}, except for paper
Humidity Operating: 10 to 80% RH
Storage: 10 to 90% RH, except for paper
Overall dimensions
(H × W × D)
Model without BP-tray
Model without LCD: 122 × 156 × 230 mm {4.80 × 6.14 × 9.06"}
Model with LCD: 147 × 156 × 236 mm {5.83 × 6.14 × 9.29"}
Model with BP-tray
147 × 156 × 328 mm {5.83 × 6.14 × 12.91"}
Weight (mass) Approx. 2.8 kg {6.2 lb}
