Epson TM-L500A User Manual

6 TM-L500A User’s Manual
English
Purpose of This Manual
This manual provides information describing basic operations to operators of the
TM-L500A to enable safe and correct use of the printer.
Important Safety Information
This section presents important information intended to ensure safe and effective
use of this product. Read this section carefully and store it in an accessible
location.
Key to Symbols
The symbols in this manual are identified by their level of importance, as defined
below. Read the following carefully before handling the product.
WARNING:
Warnings must be followed carefully to avoid serious bodily injury.
CAUTION:
Cautions must be observed to avoid minor injury to yourself, damage to your
equipment, or loss of data.
Note:
Notes have important information and useful tips on the operation of your equipment.
Safety Precautions
WARNING:
Shut down your equipment immediately if it produces smoke, a strange odor, or
unusual noise. Continued use may lead to fire. Immediately unplug the
equipment and contact your dealer or a Seiko Epson service center for advice.
Never attempt to repair this product yourself. Improper repair work can be
dangerous.
Never disassemble or modify this product. Tampering with this product may
result in injury or fire.
Use the specified AC adapter (Epson Model M159B (PS-180)) only. Connection
to an improper power source may cause fire.
Do not allow foreign matter to fall into the equipment. Penetration by foreign
objects may lead to fire.
If water or other liquid spills into this equipment, unplug the power cord
immediately, and then contact your dealer or a Seiko Epson service center for
advice. Continued usage may lead to fire.
Do not use aerosol sprayers containing flammable gas inside or around this
product. Doing so may cause fire.
CAUTION:
Do not connect cables in ways other than those mentioned in this manual.
Different connections may cause equipment damage and burning.
Be sure to set this equipment on a firm, stable, horizontal surface. Product may
break or cause injury if it falls.
Do not use in locations subject to high humidity or dust levels. Excessive humidity
and dust may cause equipment damage or fire.

Epson TM-L500A Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	184.10 mm
Supported paper width	82 mm
Product color	Gray
USB port	Yes
Standard interfaces	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
AC input voltage	24 V
Power consumption	2000 mA
Installation	Horizontally
Safety	TÜV, GOST-R
Certification	CE
Built-in barcodes	AZTECCODE, Code 128 (A/B/C), Code 39, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, PDF417, QR Code
Country of origin	China
Autocutter durability	1 million cuts
Built-in sensors details	Black Mark Sensor, Cover Open Sensor
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Print head life	100 km
Ethernet LAN	No
Pallet width	800 mm
Pallet height	2062 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2676 mm
Quantity per pallet	72 pc(s)
Quantity per pallet (UK)	96 pc(s)
Quantity per pallet layer	9 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	12 pc(s)
Package depth	387 mm
Package width	246 mm
Package height	239 mm
Package weight	3840 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	230 mm
Width	156 mm
Height	122 mm
