Epson TM L90 User Manual

10 TM-L90 User’s Manual
English
4. Push the roll paper spacer until you feel it clicks onto the shaft.
Check that the roll paper spacer slides smoothly to the left and right.
5. Slide the roll paper spacer to the appropriate width.
You can use the measurement printed inside the printer, aligning the inside edge of
the spacer with the desired measurement.
Note:
When you want to set the roll paper width from 61 mm to 70 mm, break off by
hand the two tabs of the spacer. (You can still also use widths from 38 mm to
60 mm with the spacer with the tabs broken off.)
6. Tighten the spacer with the screw included with the spacer.
(Although there are two holes, this is the only one to put the screw in.)
Shaft
Inside edge
Hook
Ruler
Hole for screw

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
