Epson TM L90 User Manual

8 TM-L90 User’s Manual
English
Installing the Printer
You must install this printer vertically (with the paper exit at the front).
If the paper exit is blocked by label backing paper accumulating on a table or other surface,
a paper jam or other problem may occur. Install the printer in a location, such as at the
edge of a counter, where the backing paper will not accumulate near the paper exit.
CAUTION:
Never install the printer in locations that receive direct sunlight. The diffuse
reflection from the roll paper may cause the label peeler detector to malfunction.
Note:
You can install it either on a flat surface, or you can hang it on a wall by using the
optional bracket (WH-10).
To hang the printer on the wall, see the Wall Hanging Bracket Set Installation
Manual provided with the WH-10 for instructions.
WARNING:
When hanging the printer on the wall with the hanging bracket set, be
sure to attach a connector cover to the printer.

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
