Epson tm-m30 User Manual

35
Chapter 3 Using the Printer Driver
3
5
Edit the logo image.
6
After editing the logo image, click the [Register] button to save the logo.
Click the [Test Print Registered Logo] button to test-print the registered logo. Click the [Unregister]
button to cancel the registration of the logo.
7
When setting a logo in multiple positions, repeat steps 2 to 6.
Setting Description
Layout Specifies [Left], [Center], or [Right] for the logo position.
Rotate by 180 Degrees When this is selected, the logo is rotated 180 degrees. Only the image is rotated,
the logo insertion position does not change.
Grayscale Specifies the grayscale setting. Selects [Multi-tone] or [Monochrome].
Paper width Sets the paper width. Select [80 mm] or [58 mm] as appropriate for the printer
paper size.
Brightness Moves the slide bar to set the brightness.

Epson tm-m30 Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Bluetooth	Yes
USB connector	USB Type-A / USB Type-B
Standard interfaces	Bluetooth, Ethernet, NFC, USB
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Country of origin	China
Autocutter durability	1.5 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Power supply type	AC
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Supported paper width	58 - 80 mm
Storage temperature (T-T)	5 - 45 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	-20 - 60 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	190 mm
Package height	230 mm
Package weight	2040 g
Quantity per pack	1 pc(s)
Pallet width	800 mm
Pallet height	2070 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)

Weight and Dimensions

Width	127 mm
